AI MDVR | 12CH Blind Spot Detection MDVR | Mobile Digital Video Recorder | Fleet Management Platform
- Model
- 12CH-MR930
Item specifics
- Voltage
- 12/24V
- Video Record Resolution
- 1920x1080
- Satellite Positioning
- Support GPS and BD (Beidou) dual-mode positioning
- Optional
- I/O or RS232
- Wireless Communication
- 4G or Wifi
- Storage
- 512GB TF Card
- Size
- 98*88*35mm
- Video Encoding
- H.264/H.265
- Application
- Suitable for All Vehicles
- Operating Temperature
- -20℃ ~ 70℃
- Warranty
- 2 years
Review
Description
12CH-MR930
Safety Driving System
● Earthquake-resistant Design: Strong earthquake resistance, flexible and convenient installation, powerful functions and high reliability.
● Exclusive Pre-installed Vehicle System: ensure data security, stability and integrity.
● BSD & 3D 360°AVM: 4/5/8/9/12/13CH optional, AI algorithm MDVR can detect 360° pedestrians and vehicles in front, side and rear of the vehicle in real time to avoid accidents caused by blind spots.
● ADAS&DMS: Integrated AI ADAS+DMS algorithm to realize driving assistance and fatigue monitoring functions. Intelligent MDVR has recognition, warning, recording and remote reporting functions to improve driving safety in fleet management.
● APC: With passenger flow statistics function: using deep learning technology, it can realize real-time recognition and motion tracking of people in the collected images, so as to achieve high-precision passenger flow statistics
● Video recording function: Full HD image; support multiple modes to trigger recording; support 10 seconds pre-recording, convenient for evidence collection
● H.264/H.265: support dual compression, improve the utilization of storage space and wireless network traffic, and combine AI with ROI processing
● Fleet management: PC/mobile terminal remote real-time monitoring, historical trajectory and video query, dangerous events can be uploaded to the vehicle monitoring platform to achieve efficient fleet management
● GPS/Beidou3G/4G/WIFI Real-time monitoring module expansion.
● Support functions: power-off time-lapse recording, low voltage protection, vehicle speed, temperature, fuel consumption, tire pressure, radar, vehicle weight, OBD, voice intercom, door switch, vibrator and other sensors
Technical Parameters
Item Type: | Fatigue Warning Alarm Device | |||
| Power Input | 12V/24V | |||
| Minimum Working Voltage/Current: | 4.75V, 320mA | |||
| Maximum Working Voltage/Current: | 5.25V, 500mA | |||
Function: | Fatigue Detection and Alarm；Distraction Detection with Alarm；1-2 Second Alarm Response；60° Detection Angle | |||
Interface: | USB | |||
Working Temperature: | -20℃-60℃ | |||
